2A Series-3150A AL

Add to quote
2A series-BIL45kV 3150A AL epoxy bushing
Stud and spade material: 6101-T63 tin-plated, inner spade 4 holes, external spade hole see table.

Electrical conductivity: 56% IACS(20℃)

Current Rating: 3150A

Voltage Rating: 2.5kV, BIL45kV

Application temperature: -40~130℃

Tank hole diameter: ï¿ 77.8, 4-bolts assembly.

2A series 3150A AL epoxy bushing

PN Ex-SPD holes Ex vs In spade L
inch mm
2A407523G01 6 In-line 17 435
2A407524G01 8 In-line 19 480
2A407525G01 10 In-line 21 524
2A407526G01 12 In-line 22 569
2A407527G01 14 In-line 24 613
2A407528G01 16 In-line 26 657
2A407529G01 18 In-line 28 702
2A40752AG01 20 In-line 29 746
2A407523G02 6 Rot-90 17 435
2A407524G02 8 Rot-90 19 480
2A407525G02 10 Rot-90 21 524
2A407526G02 12 Rot-90 22 569
2A407527G02 14 Rot-90 24 613
2A407528G02 16 Rot-90 26 657
2A407529G02 18 Rot-90 28 702
2A40752AG02 20 Rot-90 29 746
