3B Series-2200-4515A CU

Add to quote
3B series- BIL45kV 2200~4515A CU epoxy bushing
Stud and spade material: C11000 tin-plated, inner spade 2 holes, external spade hole see table.

Electrical conductivity: 101% IACS(20℃)

Current Rating: 2200A、3300A、4515A

Voltage Rating: 2.5kV BIL45kV

Application temperature: -40~130℃

Tank hole diameter: ￠77.8. 4-bolts assembly.

3B series 2200~4515A CU epoxy bushing

PN Ex-SPD holes Ex vs In spade L
inch mm
3B403823G01 6 In-line 15 392
3B403824G01 8 In-line 17 437
3B403825G01 10 In-line 19 481
3B403826G01 12 In-line 21 526
3B403827G01 14 In-line 22 570
3B403828G01 16 In-line 24 614
3B403829G01 18 In-line 26 659
3B40382AG01 20 In-line 28 703
3B405023G01 6 In-line 15 392
3B405024G01 8 In-line 17 437
3B405025G01 10 In-line 19 481
3B405026G01 12 In-line 21 526
3B405027G01 14 In-line 22 570
3B405028G01 16 In-line 24 614
3B405029G01 18 In-line 26 659
3B40502AG01 20 In-line 28 703
3B407523G01 6 In-line 15 392
3B407524G01 8 In-line 17 437
3B407525G01 10 In-line 19 481
3B407526G01 12 In-line 21 526
3B407527G01 14 In-line 22 570
3B407528G01 16 In-line 24 614
3B407529G01 18 In-line 26 659
3B40752AG01 20 In-line 28 703
3B403823G02 6 Rot-90 15 392
3B403824G02 8 Rot-90 17 437
3B403825G02 10 Rot-90 19 481
3B403826G02 12 Rot-90 21 526
3B403827G02 14 Rot-90 22 570
3B403828G02 16 Rot-90 24 614
3B403829G02 18 Rot-90 26 659
3B40382AG02 20 Rot-90 28 703
3B405023G02 6 Rot-90 15 392
3B405024G02 8 Rot-90 17 437
3B405025G02 10 Rot-90 19 481
3B405026G02 12 Rot-90 21 526
3B405027G02 14 Rot-90 22 570
3B405028G02 16 Rot-90 24 614
3B405029G02 18 Rot-90 26 659
3B40502AG02 20 Rot-90 28 703
3B407523G02 6 Rot-90 15 392
3B407524G02 8 Rot-90 17 437
3B407525G02 10 Rot-90 19 481
3B407526G02 12 Rot-90 21 526
3B407527G02 14 Rot-90 22 570
3B407528G02 16 Rot-90 24 614
3B407529G02 18 Rot-90 26 659
3B40752AG02 20 Rot-90 28 703
