NEMA Spades
| PN | Stud Thread | Holes | Length | Width | ||
| mm | inch | mm | inch | |||
| S152512C | 5/8”-11UNC-2B | 1×2 | 124.5 | 4.9 | 38.1 | 1.5 |
| S152514C | 5/8”-11UNC-2B | 1×4 | 215.9 | 8.5 | 38.1 | 1.5 |
| S194514B | 1.0”-14UN-2B | 1×4 | 220.5 | 8.7 | 49.3 | 1.9 |
| S125017B | 1.0”-14UN-2B | 1×7 | 323.9 | 12.8 | 31.8 | 1.3 |
| S125017D | 3/4”-16UNF-2B | 1×7 | 323.9 | 12.8 | 31.8 | 1.3 |
| AS12506B | 1.0”-14UN-2B | 1×7 | 323.9 | 12.8 | 31.8 | 1.3 |
| S352522C | 5/8”-11UNC-2B | 2×2 | 144 | 5.7 | 88.9 | 3.5 |
| S353822B | 1.0”-14UN-2B | 2×2 | 145 | 5.7 | 88.9 | 3.5 |
| S353822D | 3/4”-16UNF-2B | 2×2 | 145 | 5.7 | 88.9 | 3.5 |
| S353822A | 1.25”-12UNC-2B | 2×2 | 144 | 5.7 | 88.9 | 3.5 |
| S353822B2 | 1.00”-12UNC-2B | 2×2 | 146 | 5.7 | 88.9 | 3.5 |
| S450022A | 1.25”-12UNC-2B | 2×2 | 177.8 | 7.0 | 101.6 | 4.0 |
| S353823C | 5/8”-11UNC-2B | 2×3 | 168 | 6.6 | 88.9 | 3.5 |
| S403823B~S403828B | 1.0”-14UN-2B | 6~20 | 177.8~400 | 7.0~15.7 | 101.6 | 4.0 |
| S405023A~S40502AA | 1.25”-12UNC-2B | 6~20 | 216~527.3 | 8.5~8.5 | 101.6 | 4.0 |
| S353823C~S353825C | 5/8”-11UNC-2B | 6~10 | 177.8~311.1 | 7.0~12.2 | 88.9 | 3.5 |
| S353823D~S353825D | 3/4”-16UNF-2B | 6~10 | 177.8~311.1 | 7.0~12.2 | 88.9 | 3.5 |
